NFPA 80 Test Services

Fire doors are vital to a fire protection system's success. They protect lives and property by limiting fire passage. Depending on the specific fire door assembly, they can also limit the passage of toxic gases and smoke.

To help ensure fire doors operate safely, the National Fire Protection Association (NFPA) requires annual fire door inspections under the NFPA 80 Standard. Building owners and managers must keep written records of their fire door inspections to demonstrate compliance.

At VTEC Laboratories, we provide fast, reliable NFPA 80 testing to evaluate your fire doors' performance and help you stay compliant.

What Is the NFPA 80 Test?

NFPA 80 sets the national standard for fire door safety. It includes the minimum requirements for the installation, inspection and maintenance of fire doors and other opening protectives, such as fire shutters and windows.

At VTEC Laboratories, we offer a fire door drop test to help you stay in compliance. A drop test is required after a fire door repair or installation. NFPA 80 also stipulates that the test be performed at least annually to ensure the door works properly in a fire situation.

How We Conduct Our NFPA 80 Test

Our test includes a visual inspection, an operational check and two drop tests — one to confirm the door closes properly and one to confirm the linkage resets correctly.

During the visual inspection, we check for proper bolts, jamb attachments, fusible link locations and other details to ensure the door is properly installed. We also look for damaged or missing parts and inspect ancillary equipment like control panels and release devices.

We then test the door to make sure it operates easily with a full range of motion. If your door passes the visual and operational tests, we'll perform the drop tests in accordance with the manufacturer's instructions. Your door must fall at least 6 inches per second and not more than 24 inches per second to be in compliance.

Once we determine whether your fire door is in compliance, you'll receive an official test form with your results. If your door passes the testing, you'll also receive a certification label indicating the inspection and testing date.

Why Choose VTEC Laboratories for NFPA 80 Testing?

At VTEC Laboratories, we make it easy for you to ensure your building's fire doors are compliant with NFPA 80 standards. We've helped property owners and managers with standardized materials testing for more than 30 years. We use state-of-the-art equipment and techniques to provide thorough testing and fast results.

You can count on us to deliver a complete report in an industry-leading turnaround time. What's more, you'll gain peace of mind knowing you're working with an ISO-accredited partner that's widely recognized and accepted by authorities having jurisdiction (AHJs).

Contact Us for NFPA 80 Testing Services

VTEC Laboratories offers the testing you need to remain fully compliant. Reach out to us today to learn more about our NFPA 80 testing services or request a quote online.
